FPGA Custom Boards
Ultra-Fast Logic. Built to Your Specs. Designed for Performance
At Rennologic, we design and develop custom FPGA (Field Programmable Gate Array) boards tailored to your application’s performance, flexibility, and interface requirements. Whether you're building a high-speed signal processing unit, a custom protocol handler, or a reconfigurable control platform, our FPGA boards deliver unmatched speed and hardware-level control.
From architecture planning and HDL coding to PCB design, testing, and integration — we provide a complete end-to-end solution for embedded FPGA platforms.
Applications:
-
Real-time industrial automation controllers
-
Machine vision and signal processing platforms
-
Software-defined radio (SDR) and communication systems
-
High-speed data acquisition and filtering
-
Encryption, decryption, and secure protocol handling
-
Embedded AI and neural inference accelerators
-
Sensor fusion systems in smart agriculture and defense
Key Features:
- Fully customized layout to meet performance and form-factor needs
- Support for mid-range and high-end FPGAs (Spartan, Kintex, Cyclone, MAX series, etc.)
- Flexible logic and DSP resources for real-time processing
- Onboard programmable clocks and PLLs
- Pre-loaded boot images or FPGA bitstream storage
- Option to add ARM SoCs for hybrid control (Zynq, Arria, etc.)
- Interfaces for ADC/DACs, external memory, or sensors
- Reconfigurable logic blocks for future firmware updates
- Designed for low-power and high-speed applications
- Industrial-grade temperature and voltage tolerance
Technical Specifications:
| Specification | Value |
|---|---|
| FPGA Vendor Support | Xilinx, Intel/Altera, Lattice |
| Logic Resources | From 10K to 1M+ Logic Elements |
| Memory Options | DDR3/DDR4 (up to 8GB), QSPI Flash |
| Clock Speeds | Up to 500 MHz internal / configurable |
| I/O Interfaces | UART, SPI, I2C, GPIO, USB, HDMI, Ethernet |
| PCB Layers | 4–10 layers (as needed) |
| Power Supply Input | 5V–24V (regulated) |
| Board Size | Custom: Pico to full-size boards |
| Compliance | RoHS, CE (on request) |
